bituminous underlay - E-BP3-700

Vapour barrier underlay with excellent waterproofing properties

BARRIERA AL VAPORE VAPOUR BARRIER
ARMATURA IN POLIESTERE POLYESTER CARRIER
ANTISCIVOLO ANTISKID
IMPERMEABILE WATERPROOFING
 LEGGERO LIGHT
TETTO ROOF
CHARACTERISTICS

Waterproofing and vapour barrier underlay composed of a polyester carrier saturated with an exclusive bituminous compound and protected by non-woven polypropylene. Characterized by excellent waterproofing properties. Stabilized against UV rays.

APPLICATIONS

Underlay for discontinuous roofing. It is recommended to use it on the second deck, more exposed to the elements and where the fixings often have larger sections, thus favoring the rapid and safe conveyance of rainwater and its rapid transfer to the eaves line. The high weight makes it an optimal product in regions characterized by a harsh climate or by high temperature ranges.

Contact us
DATA SHEET
CHECKED CHARACTERISTICS NORM UNIT OF MEASURE VALUE
Mass per unit area EN 13859-1 g/m2 700±5%
Thickness EN 1849-1 mm 0,9±15%
Tensile strength

EN 13859-1

N/5cm MD: 530±15%
CD: 350±15%
Elongation EN 13859-1 % MD: 30-50%
CD: 40-60%
Nail tearing

EN 13859-1

N MD: 200±20%
CD: 200±20%
Resistance to water penetration EN 13859-1   Class W1
Water impermeability EN 20811 m 7 (average value)
minimum: 5
Artificial ageing
Tensile strength after ageing
Resistance to water penetration after ageing
EN 13859-1 N/5cm MD: 503±20%
CD: 330±20%
Class W1
UV resistance Internal method   4 months
Water vapour transmission property

EN 13859-1

g/m² x 24h
m
WDD: 0,45±15%
Sd= 95
23°C 0/75% RH
Dimensional stability EN 13859-1
(80°C)
% -0,5<ΔL<0,5
Flexibility at low termperature EN 13859-1 °C -40

For information regarding use, handling, storage and security see DOP
Product subject to CE mark according to EN 13859-1
